MASTER B 70 CED direct oil heater
Power:
20 kW
70.000 Btu/h
17.500 Kcal/h
| Air displacement: | Fuel consumption: | Tank capacity: | Dimensions (l x w x ht): |
| 400 m3/h | 1,7 kg/h | 19 l | 810 x 350 x 450 mm |
| Power supply: | Rated current: | Thermostat control: | Net / gross weight: |
| 220-240/50 V/Hz | 1,0 A | optional | 17 / 19 kg |
| Pallet: | |||
| 15 pcs |
Main features
Model descriptionThermally protected motor Electronic flame control with photocell Possible connection to an optional room thermostat Stainless steel combustion chamber Oil tank included Durable external powder coating Strong and long lasting construction Housing remains cool to the touch Easy to move High air displacement Easy maintenance Two oil filters: oil tank filter and suction filter | | |
How it worksConbustion system - air flow  | |
